LNK Inserts
The LNK is a range of inserts provided by Seco®.

Features of the LNK 05, 06, and 08 inserts:

• Very tough inserts designed for weaker machines or unstable machining conditions; these cutters have fewer teeth engaged in the cutting process

• Surface finish below Ra <2 μm

• Widths from 8 – 15 mm (.390" - 1.20") for adjustable pocket configuration

• Widths from 8 – 20 mm (.312" - .750") for fixed pocket version

Read more about the LNK inserts in the Disc Mill Selection Guide found in the menu bar on the right.
______________________________________________________________________



SNHQ Inserts
One of the inserts offered by Seco® is the SNHQ insert.

Features of the SNHQ inserts include:

• Higher metal removal rate achieved under stable machining conditions

• Excellent results for light cutting applications

• Right or left handed

• Four-edged inserts available with corner radii from 0,2 – 2,0 mm (.008" - .079")

• Two-edged inserts available with corner radii from 2,0 – 6,0 mm (.079" - .236")

• SNHQ is a direct replacement for the 335.19 inserts, but provide additional features like wiper flats and more radius options

• Full radii on every width

Read more about the SNHQ inserts in the Disc Mill Selection Guide found in the menu bar on the right.
